1/2″ Jumper Cable, 7/16 RA Male-7/16 Female

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

1/2″ Jumper Cable, 7/16 RA Male-7/16 Female

Jumper cables are used mainly between main feeders and antennas or between main feeders and system equipment. 7/16 RA Male-7/16 Female jumper cable is made of  1/2″ super flexible coaxial cable, 7/16 right angle male connector and 7/16 straight female connector.

Quality of the product is tested according to IEC and MIL Standards , as a result is reflected in their high quality and reliability. Furthermore security of the joint and their concentric is guaranteed by a tight plastic cover.

• Low attenuation and VSWR (< 1.1)
• Length of cable depending on customer request
• Factory made
• 100 % PIM and RL tested and serialized
• Cost-effective
Flexible (Minimum Bending Radius :25mm)
• Degree of protection: IP 68 compliant with IEC60529
• High reliability, safety, UV protected & fire retardant
• Optimized to provide high performance in telecommunication networks
• Fast installation without the need for any additional expensive tools
• Cable and connectors have been soldered together in the production operation
• Compliant with RoHS

Materials Specifications
Cable 1/2″  Super Flexible
Jumper Type
Factory-Fit (Standard)
Length, m
3m, Based on customer requirements
Impedance
50 ± 1 Ω
Connector A 7-16 DIN Male Right-angle
Connector B 7-16 DIN Female Straight
Intermodulation, 3rd Order, dBc ≤ -160
Insulation Resistance MΩ
 ≥ 100000
DC Breakdown Voltage (4kV,A.C.,1min) No Breakdown or Flashover
VSWR
≤1.10 @ DC-2700 MHz
Minimum Bending Radius, mm
25
Degree of protection
IEC 60529, IP68
High Temperature Test
No Abnormality
Low Temperature Test
No Abnormality
