Jumper Cable, 4.3-10 Male/ 4.3-10 Male Straight
Please do not hesitate to contact us if you require any further information
4.3-10 male straight jumper cable
The 4.3-10 male/ 4.3-10 male straight jumper cable is made from 1/2 SCF coaxial cable and new generation connectors required by 5G, LTE & smallcell.
Quality of the product is tested according to IEC and MIL Standards , as a result is reflected in their high quality and reliability. Furthermore security of the joint and their concentric is guaranteed by a tight plastic cover.
• Commonly used for connecting RF cable lines with antenna or radios
• High quality and excellent performances
• VSWR<1.1 @ DC-3700 MHz and order IMD >160 dBc (100% tested and recorded)
• Available in variety of coaxial cables and RF connectors
• 1/2″ super flexible coaxial cable (length of cable depending on customer request )
• Flexible
• Degree of protection: IP 68 compliant with IEC 60529
• High reliability, safety, UV protected & fire retardant
• Optimized to provide high performance in
telecommunication networks
• Fast installation without the need for any additional expensive tools
• Compliant with MIL, IEC and RoHS & CRoHS
| Technical Specification | |
| Cable Type | 1/2 ” Superflexible, UV Protected |
| Jumper Type | Factory-Fit (Standard) |
| Length | 3m, 5m, 7m, 10m & according to request of customer |
| Connector A | 4.3/10 Male straight |
| Body | Brass, Tri-Metal plated |
| Center Contact Connector A | Brass, Ag plated |
| Body | Brass, Tri-Metal plated |
| Dielectric | PTFE |
| Connector B | 4.3/10 Male Straight |
| Body | Brass, Tri-Metal plated |
| Dielectric | PTFE |
| Center Contact Connector B | Brass, Ag plated |
| Gasket | Silicone rubber |
| Jacket | Black Polyethylene |
| Characteristic Impedance | 50±1 Ω |
| Insulation Resistance | ≥ 100000 MΩ |
| VSWR | ≤1.1 @ DC-2700 MHz |
| Minimum Bending Radius | 25 mm |
| Degree of protection | IP68, IEC 60529 |
| Working Temperature | -40 °C to +85 °C |
| Standard | IEC-61169-54 |
