RF Jumper cables are used mainly between main feeders and antennas or between main feeders and system equipment. 4.3/10 male-7/16 male Straight jumper cable is made from 1/2 SCF coaxial cable and RF connectors required by 3G, LTE, 5G & small cell.
Quality of the product is tested according to IEC and MIL Standards , as a result is reflected in their high quality and reliability. Furthermore security of the joint and their concentric is guaranteed by a tight plastic cover.
• Commonly used for connecting RF cable lines with antenna or radios
• Approved by Iranian National Standards Organization and Mobile Network Operators
• High quality and excellent performances
• VSWR<1.1 @ DC-3700 MHz and order IMD >160 dBc (100% tested and recorded)
• Available in variety of coaxial cables and RF connectors
• 1/2″ super flexible coaxial cable (length of cable depending on customer request )
• Flexible (Minimum Bending Radius :25mm)
• Degree of protection: IP 68 compliant with IEC 60529
• High reliability, safety, UV protected & fire retardant
• Optimized to provide high performance in telecommunication networks
• Fast installation without the need for any additional expensive tools
• Compliant with MIL, IEC and RoHS & CRoHS
Technical Specification | |
Cable Type | 1/2 ” Superflexible, UV Protected |
Jumper Type | Factory-Fit (Standard) |
Length | 1m,3m, 5m, 7m, 10m & according to request of customer |
Connector A | 4.3/10 Male straight |
Body | Brass, Tri-Metal plated |
Center Contact Connector A | Brass, Ag plated |
Body | Brass, Tri-Metal plated |
Dielectric | PTFE |
Connector B | 7/16 Male Straight |
Body | Brass, Tri-Metal plated |
Dielectric | PTFE |
Center Contact Connector B | Brass, Ag plated |
Gasket | Silicone rubber |
Jacket | Black Polyethylene |
Characteristic Impedance | 50±1 Ω |
Insulation Resistance | ≥ 100000 MΩ |
VSWR | ≤1.1 @ DC-2700 MHz |
Minimum Bending Radius | 25 mm |
Degree of protection | IP68, IEC 60529 |
Working Temperature | -40 °C to +85 °C |
Standard | IEC-61169-54, IEC-61169-4 |
