• 1/2″ Jumper Cable, 4.3/10 male-n type male
  • 1/2″ Jumper Cable, 4.3/10 male-n type male
  • 4.3-10-NM-jumper
  • جامپر سال 1393
  • 4.3m 7/16 M Jumper cable
  • 1/2″ Jumper Cable, N Type Male -N Type Female Straight

1/2″ Jumper Cable, 4.3/10 male-N Type male Straight

Please do not hesitate to contact us if you require any further information

1/2″ Jumper Cable, 4.3/10 male-N Type male Straight

RF Jumper cables are used mainly between main feeders and antennas or between main feeders and system equipment. 4.3/10 male-N type male straight  jumper cable is made from 1/2 SCF and RF connectors required by 3G, LTE, 5G & small cell.

Quality of the product is tested according to IEC and MIL standards , as a result is reflected in their high quality and reliability. Furthermore security of the joint and their concentric is guaranteed by a tight plastic cover.


• Commonly used for connecting RF cable lines with antenna or radios
• Approved by Iranian National Standards Organization and Mobile Network Operators
• High quality and excellent performances
• VSWR<1.1 @ DC-3700 MHz and order IMD >160 dBc (100% tested and recorded)
• Available in variety of coaxial cables and RF connectors
1/2″ super flexible coaxial cable (length of cable depending on customer request )
• Flexible (Minimum Bending Radius :25mm)
• Degree of protection: IP 68 compliant with IEC 60529
• High reliability, safety, UV protected & fire retardant
• Extra durability
• Fast installation without the need for any additional expensive tools
• Manufactured and tested compliant with  with MIL, IEC and RoHS

Technical Specification
 Cable Type 1/2 ” Superflexible, UV Protected
Jumper Type Factory-Fit (Standard)
Length  3m,  & according to request of customer
Connector A 4.3/10 Male straight
Body Brass, Tri-Metal plated
Center Contact Connector A Brass, Ag plated
Body Brass, Tri-Metal plated
Dielectric PTFE
Connector B N-Type Male Straight
Body Brass, Tri-Metal plated
Dielectric PTFE
Center Contact Connector B Brass, Ag plated
Gasket Silicone rubber
Jacket Black Polyethylene
Characteristic Impedance 50±1 Ω
Insulation Resistance ≥ 100000 MΩ
VSWR ≤1.1 @ DC-2700 MHz
Minimum Bending Radius 25 mm
Degree of protection IP68, IEC 60529
Working Temperature -40 °C to +85 °C
Standard IEC-61169-16, IEC-61169-54
