7/16 RA male to 4.3-10 male 1/2″ Jumper

Please do not hesitate to contact us if you require any further information

7/16 RA male to 4.3-10 male 1/2″ Jumper

The 7/16 RA male to 4.3-10 male 1/2″ Super Flexible Jumper, is designed and manufactured of new generation connectors required by 5G, LTE & small-cell and has high performance.
Quality of the product is tested according to IEC and MIL Standards , as a result is reflected in their high quality and reliability. Furthermore security of the joint and their concentric is guaranteed by a tight plastic cover.

• Low attenuation and VSWR (≤1.1@3GHz)
100%  tested according to IEC and MIL Standards
• 1/2″ super flexible coaxial cable (length of cable depending on customer request )
•
High flexibility of these jumpers is due to their unique design.
• Degree of protection: IP 68 compliant with IEC 60529
• High reliability, safety, UV protected
• Optimized to provide high performance in telecommunication networks
• Fast installation without the need for any additional expensive tools
• Compliant with RoHS

Technical Specification
1/2 Super Flexible Cable Type
Factory-Fit (Standard) Jumper Type
According to customer requirements Length, m (ft)
7-16 DIN Male Right Angle Connector A
Brass, silver plated Center Contact Connector A
Brass, Tri-Metal plated Outer Contact Connector A
Brass, Tri-Metal plated Body Connector A
4.3-10 Male Straight Connector B
Brass, silver plated Center Contact Connector B
Brass, white bronze plated Outer Contact Connector B
Brass, Tri-Metal plated Body Connector B
PTFE Dielectric
Silicone rubber Gasket
50±1 Ω Characteristic Impedance
Black Polyethylene, Jacket
25 mm Minimum Bend Radius
≤1.1 @ 690-2690 MHz VSWR (Return Loss, dB), typical
≥160 dBc Intermodulation, 3rd Order, dBc
IP68, IEC 60529 Sealing class
-40 °C to +85 °C Operation Temperature
IEC 62037 Standard
