FCCC Jumper cable, DIN M / DIN Male RA

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

SKU: FC-JSD-716-0 Categories: , ,

FCCC Factory-Fit Jumper cable made from Hansen 1/2″ SCF and 7-16 DIN Male Right Angle connectors. Cable and connectors have been soldered together in the production operation. Security of the joint and their concentric is guaranteed by a tight plastic cover. Quality of the product is tested according to IEC and MIL Standards. The connector design and manufacturing process has been optimized to produce premium VSWR and IM levels. The RFS Jumper is commonly used for for the connection of the RF cable lines with the antenna or with the radios in wireless systems.



• Low and Stable premium VSWR
• Low and consistent intermodulation performance
• High quality and excellent performances
• Low attenuation and VSWR
• Waterproof to safety class IP 68
• Available with flame retardant jacket types
• Available in variety of lengths and connectors
• Compliant to RoHS (EU) and CRoHS (China)





Technical Specification
 Hansen 1/2″ Superflexible Foam Cable Type
Factory-Fit (Standard) Jumper Type
5 m Lenght
7-16 DIN Male Right Angle Connector A
Brass, silver plated Center Contact Connector A
Hexagon nut, Nickel plated Coupling Nut Connector A
Trimetal plated Outer Contact Connector A
7-16 DIN Male Right Angle Connector B
Brass, silver plated Center Contact Connector B
Trimetal plated Outer Contact Connector B
Hexagon nut, Nickel plated Coupling Nut Connector B
PTFE Dielectric
Silicone rubber Gasket
IP68 Sealing class
Black Polyethylene, Halogen-free acc. IEC 60754-1 and -2 Jacket
Single: 25
Repeted: 30
Moving: 200
Minimum Bend Radius, mm
≤1.15  @ 820 – 960 MHz
≤1.15 @ 1700 – 2200 MHz
≤1.15 @ 2300 – 2400 MHz
≤1.15 @ 2500 – 2700 MHz
VSWR (Return Loss, dB), typical
-155 (typical) Intermodulation, 3rd Order, dBc
Store -70~+85
Installation -40~+60
Operation -55~+85
Store -30~+80
Installation -25~+60
Operation -30~+80
PE jacket

Fire retardant
PE jacket

Temperature, °C
