1/2″ Jumper Cable, 7/16 male-7/16 male

Please do not hesitate to contact us if you require any further information

1/2″ Jumper Cable, 7/16 male-7/16 male
The 7/16 male-7/16 male straight  jumper cable
 is made from 1/2 SCF coaxial cable and RF connectors required by 3G, LTE, 5G & smallcell.


• Commonly used for connecting RF cable lines with antenna or radios
• High quality and excellent performances
• VSWR<1.1 @ DC-3700 MHz and order IMD >160 dBc (100% tested and recorded)
• Available in variety of coaxial cables and RF connectors
1/2″ super flexible coaxial cable (length of cable depending on customer request )
• Flexible
• Degree of protection: IP 68 compliant with IEC 60529
• High reliability, safety, UV protected & fire retardant
• Optimized to provide high performance in
telecommunication networks
• Fast installation without the need for any additional expensive tools
• Compliant with MIL, IEC and RoHS & CRoHS

Technical Specification
 Cable Type 1/2 ” Superflexible, UV Protected
Jumper Type Factory-Fit (Standard)
Length  3m,  & according to request of customer
Connector A 7/16 Male straight
Body Brass, Tri-Metal plated
Center Contact Connector A Brass, Ag plated
Body Brass, Tri-Metal plated
Dielectric PTFE
Connector B 7/16 Male Straight
Body Brass, Tri-Metal plated
Dielectric PTFE
Center Contact Connector B Brass, Ag plated
Gasket Silicone rubber
Jacket Black Polyethylene
Characteristic Impedance 50±1 Ω
Insulation Resistance ≥ 100000 MΩ
VSWR ≤1.1 @ DC-2700 MHz
Minimum Bending Radius 25 mm
Degree of protection IP68, IEC 60529
Working Temperature -40 °C to +85 °C
Standard IEC-61169-4
