7/16 male jumper cable

Jumper 5m M M

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

FCCC Factory-Fit Jumper cable made from 1/2″ superflexible RF cable and 7-16 DIN Male Right Angle connectors. Cable and connectors have been soldered together in the production operation. Security of the joint and their concentric is guaranteed by a tight plastic cover. Quality of the product is tested according to IEC and MIL Standards. The connector design and manufacturing process has been optimized to produce premium VSWR and IM levels. The Jumper is commonly used for for the connection of the RF cable lines with the antenna or with the radios in wireless systems.

 Applications :
• GPS
• CATV
• LAN/WAN

• High quality and excellent performances
• High reliability and safety
• Fast and easy installation
• Low attenuation and low loss and low VSWR
• Waterproof to safety class IP 68

• Available with flame retardant jacket types
• High operating voltage
• Flexible
• High dimensional stability



Technical Specifications
½ superflexible Cable Type
Factory-Fit (Premium) Jumper type
7/16 Male-Male Connector type
5m Length ,m (ft)
Brass, silver plated Center Contact Connector A
Brass, tri-metal plated Outer Contact Connector A
Brass, silver plated Center Contact Connector B
Brass, tri-metal plated Outer Contact Connector B
Black Polyethylene Jacket
125 (5) Minimum Bend Radius, mm (in)
DC-2700 Frequency Band(s), MHz
1-1.1 Return Loss, dB (VSWR), typical
