1/2″ Jumper Cable, N-Type Male Female Straight

Please do not hesitate to contact us if you require any further information

1/2″ Jumper Cable, N Type Male/N Type Female Straight

N-Type male N-type female jumper is made of 1/2 SCF coaxial cable with N type connectors which is used mainly between main feeders and antennas or between main feeders and system equipment.

Quality of the product is tested according to IEC and MIL Standards , as a result is reflected in their high quality and reliability. Furthermore security of the joint and their concentric is guaranteed by a tight plastic cover.

  • The N-Type male N-type female jumper is used to mate most outdoor antennas and access points.
  • Approved by Iranian National Standards Organization and Mobile Network Oprators
  • High quality and excellent performances
  • VSWR<1.1 @ DC-3700 MHz and order IMD >160 dBc (100% tested and recorded)
  • Available in variety of coaxial cables and RF connectors
  • 1/2″ super flexible coaxial cable
  • Flexible (Minimum bending radius: 25mm)
  • Degree of protection: IP 68 compliant with IEC 60529
  • High reliability, safety, UV protected & fire retardant
  • High dimensional stability
  • Optimized to provide high performance in telecommunication networks
  • Fast installation without the need for any additional expensive tools
  • Compliant with MIL, IEC and RoHS

Technical Specification
 Cable Type 1/2 ” Super flexible, UV Protected
Jumper Type Factory-Fit (Standard)
Length  3m,  & according to request of customer
Connector A N-Type Male straight
Body Brass, Tri-Metal plated
Center Contact Connector A Brass, Ag plated
Body Brass, Tri-Metal plated
Dielectric PTFE
Connector B N-Type Female Straight
Body Brass, Tri-Metal plated
Dielectric PTFE
Center Contact Connector B Brass, Ag plated
Gasket Silicone rubber
Jacket Black Polyethylene
Characteristic Impedance 50±1 Ω
Insulation Resistance ≥ 100000 MΩ
VSWR ≤1.1 @ DC-2700 MHz
Minimum Bending Radius 25 mm
Degree of protection IP68, IEC 60529
Working Temperature -40 °C to +85 °C
Standard IEC-61169-16
