N Type-Female 7/16-Male Straight Jumper Cable

Please do not hesitate to contact us if you require any further information

N type-female 7/16-male straight  jumper cable

The N type-female 7/16-male straight  jumper cable is made from coaxial cable and RF connectors.  It is Useful as a connection from your RF source ( transmitter ) to a load or watt meter and as a coaxial cable jumper from watt meters to 50 ohm load or antenna.

The jumper cables designed, manufactured and/or distributed under this quality management system (ISO9001 & ISO14001). Quality of the product is tested according to IEC and MIL Standards.


• U
sed for high-frequency signal transmission
• Security of the joint and their concentric is guaranteed by a tight plastic cover
• High quality and excellent performances
• VSWR<1.1 @ DC-3700 MHz and order IMD >160 dBc (100% tested and recorded)
• Available in variety of coaxial cables and RF connectors
1/2″ super flexible coaxial cable (length of cable depending on customer request )
•
high flexibility ( is due to their unique design)
• Degree of protection: IP 68 compliant with IEC 60529
• High reliability, safety, UV protected & fire retardant
• Optimized to provide high performance in
telecommunication networks
• Fast installation without the need for any additional expensive tools
• Compliant with MIL, IEC and RoHS & CRoHS

Technical Specification
 Cable Type 1/2 ” Superflexible, UV Protected
Jumper Type Factory-Fit (Standard)
Length 3m, 5m, 7m, 10m & according to request of customer
Connector A N-Type Female straight
Body Brass, Tri-Metal plated
Center Contact Connector A Brass, Ag plated
Body Brass, Tri-Metal plated
Dielectric PTFE
Connector B 7/16 Male Straight
Body Brass, Tri-Metal plated
Dielectric PTFE
Center Contact Connector B Brass, Ag plated
Gasket Silicone rubber
Jacket Black Polyethylene
Characteristic Impedance 50±1 Ω
Insulation Resistance ≥ 100000 MΩ
VSWR ≤1.1 @ DC-2700 MHz
Minimum Bending Radius 25 mm
Degree of protection IP68, IEC 60529
Working Temperature -40 °C to +85 °C
Standard IEC-61169-4, IEC-61169-16
