RFS Jumper cable, DIN F/M

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

Germany RFS Factory-Fit Jumper cable made from 1/2″ SCF and 7-16 DIN Female and 7-16 DIN Male Right Angle connectors. Connectors is soldered to cable in an industrial process under strict control to ensure the functioning of jumpers in high-performance wireless systems. The connector design and manufacturing process has been optimized to produce premium VSWR and IM levels. The RFS Jumper is commonly used for for the connection of the RF cable lines with the antenna or with the radios in wireless systems.



• Low and Stable premium VSWR
• Low and consistent intermodulation performance
• High quality and excellent performances
• Low attenuation and VSWR
• Waterproof to safety class IP 68
• Available with flame retardant jacket types
• Available in variety of lengths and connectors
• Compliant to RoHS (EU) and CRoHS (China)

Materials Specifications
Cable 1/2″ Superflexible Foam
Jumper Type
Factory-Fit (Standard)
Connector A
7-16 DIN Female
Center Contact Connector A
Spring bronze, silver plated
Outer Contact Connector A
Trimetal plated
Connector B 7-16  DIN Male Right Angle
Center Contact Connector B Brass, silver plated
Outer Contact Connector B Trimetal plated
Coupling Nut Connector B Hexagon nut, Nickel plated
Dielectric PTFE
Gasket Silicone rubber
Sealing class IP68
Jacket Black Polyethylene, Halogen-free acc. IEC 60754-1 and -2
Minimum Bend Radius, mm (in) 32 (1.25)
VSWR (Return Loss, dB), typical 1.106 (26) @ 410 – 470 MHz
1.106 (26) @ 820 – 960 MHz
1.106 (26) @ 1710 – 1990 MHz
1.106 (26) @ 2000 – 2200 MHz
Intermodulation, 3rd Order, dBc -155 (typical)
Installation Temperature, °C(°F)
-40 to 60 (-40 to 140 )
Operation Temperature, °C(°F)
-50 to 85 (-58 to 185 )
Storage Temperature, °C(°F)
-70 to 85 (-94 to 185 )
