مشخصات کلی General specifications |
|
کابل Cable |
1/2 ” Superflexible, UV Protected |
نوع جامپر Jumper Type |
Factory-Fit (Standard) |
طول Length, m |
1m, 3m, 5m, 7m, 10m & according to request of customer |
کانکتور A Connector A |
N male/Straight |
کانکتور B Connector B |
N male/Straight |
مشخصات الکتریکی Electrical data |
|
امپدانس Impedance |
50 ± 1 Ω |
Intermodulation, 3rd Order, dBc | ≤ -160 |
مقاومت عایق MΩ Insulation Resistance MΩ |
≥ 100000 |
DC Breakdown Voltage (4kV,A.C.,1min) | No Breakdown or Flashover |
VSWR |
≤1.1 @ 690-2690 MHz |
مشخصات مکانیکی و محیطی Mechanical & Environmental data |
|
حداقل شعاع خمش, mm Minimum Bending Radius, mm |
25 |
طبقه حفاظت Degree of protection |
IP68, IEC 60529 |
دمای عملیاتی Working Temperature |
-40 C to +85 C |
