Simplex Fiber Optic Pigtail, Multi-mode, 3mm

Simplex Fiber Optic Pigtail, Multimode, 3mm

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

SKU: SABA-Pig-I-MM-Si-30 Categories: ,

multimode fiber pigtail is used for telecom networks and also used for high speed metropolitan and access network.



Telecommunication Networks

Local Area Network (LAN)

Connects Between fiber optic patch panel & network Switch

  • SC, LC, ST and FC connectors
  • High return loss and low insertion loss
  • High reliability and small bend radius
  • Good exchangeability
  • High tensile strength
  • Available in low smoke zero halogen (LSZH) jacket
  • Available in different fiber types and lengths
  • Conforms to IEC, EIA-TIA performance requirements
  • Lifetime Warranty
  • Ceramic ferrules
  • Guaranteed quality and performance
  • 100% tested and recorded for insertion loss and return loss
  • RoHS Compliant
  • Semi tight buffered easy strip fiber
Electrical and mechanical specification
Data Item
Optic Fiber Pigtail, Multi-mode, 3mm Product name
SC/ST/FC/LC Connector type
MM 3mm Product type
According to request of customer Length
PVC or LSZH or OFNR or OFNP(on request) Cable jacket type
Simplex Fiber Count
OM1, OM2, OM3, OM4 Fiber type
<0.2dB Insertion Loss
PC>45 dB , UPC>55 dB , APC>60 dB Return loss
≤0.2 dB 1000 times mating cycles Repeatability
3 mm Cable Diameter
Orange, Aqua Jacket Color
-40ºC to +85ºC Operating Temperature
IEC 60784-1, IEC 61300, GR-326-CORE, GR-1435, ISO/IEC 11801, AS/NZS ISO/IEC 14763.3, IEC 61280-4-1, UL 94, ANSI/TIA-598C & RoHS Standard
Item Connector Type Ferrule Type Fiber Type Cable Type Jacket Material Cable Color Cable Diameter Cable Length

Fiber Optic Pigtail

SC UPC G.652.D Single Mode 9/125 SX Simplex P PVC Y Yellow 9 0.9mm 01 01 m
G.657.A1 Single Mode 9/125
LC G.657.A2 Single Mode 9/125 O Orange
02 02 m
G.655 Single Mode 9/125 20 2.0mm
W Orange
ST OM1 Multi Mode 50/125
APC OM2 Multi Mode 50/125 DX Duplex L LSZH A Aqua
OM3 Multi Mode 50/125 B Blue 30 3.0mm
99 99 m
MU OM4 Multi Mode 50/125 G Green
