Simplex Fiber Optic Pigtail, Multi-mode, 2mm
Please do not hesitate to contact us if you require any further information
Foreign Commercial Manager : +989125708854
Multi-mode Fiber Optic Pigtail is basically used to splice the fiber in the cable so that they can be connected to the patch panel or equipment. It comprises of a fiber cable terminated with a connector at only one end while the other end will be used for the splicing to cable. Pigtails come in many variations for fibers, cables and connectors.
Applications:
Pigtails are used for It is suitable to use in telecommunication network, Local area network (LAN), Metropolitan area network (MAN), Wide area network (WAN), Test equipment, Data processing network, Interconnection for O/E modules and Optical switch interface connection.
- SC, LC, ST and FC connectors
- High return loss and low insertion loss
- High reliability and small bend radius
- Good exchangeability
- High tensile strength
- Available in low smoke zero halogen (LSZH) jacket
- Available in different fiber types and lengths
- Conforms to IEC, EIA-TIA performance requirements
- Lifetime Warranty
- Ceramic ferrules
- Guaranteed quality and performance
- 100% tested and recorded for insertion loss and return loss
- RoHS Compliant
- Semi tight buffered easy strip fiber
| Electrical and mechanical specification | |
| Data | Item |
| Optic Fiber Pigtail, Multi mode, 2mm | Product name |
| SC/ST/FC/LC/DIN | Connector type |
| MM 2mm | Product type |
| According to request of customer | Length |
| PVC or LSZH or OFNR or OFNP(on request) | Cable jacket type |
| Simplex | Fiber Count |
| OM1, OM2, OM3, OM4 | Fiber type |
| <0.2dB | Insertion Loss |
| PC>45 dB , UPC>55 dB , APC>60 dB | Return loss |
| ≤0.2 dB 1000 times mating cycles | Repeatability |
| 2 mm | Cable Diameter |
| Orange, Aqua | Jacket Color |
| -40ºC to +85ºC | Operating Temperature |
| IEC 60784-1, IEC 61300, GR-326-CORE, GR-1435, ISO/IEC 11801, AS/NZS ISO/IEC 14763.3, IEC 61280-4-1, UL 94, ANSI/TIA-598C & RoHS | Standard |
| Item | Connector Type | Ferrule Type | Fiber Type | Cable Type | Jacket Material | Cable Color | Cable Diameter | Cable Length | |||||||
Fiber Optic Pigtail |
SC | UPC | G.652.D | Single Mode 9/125 | SX | Simplex | P | PVC | Y | Yellow | 9 | 0.9mm | 01 | 01 m | |
| G.657.A1 | Single Mode 9/125 | ||||||||||||||
| LC | G.657.A2 | Single Mode 9/125 | O | Orange | |||||||||||
| 02 | 02 m | ||||||||||||||
| G.655 | Single Mode 9/125 | 20 | 2.0mm | ||||||||||||
| G | Green | ||||||||||||||
| ST | OM1 | Multi Mode 61.5/125 | |||||||||||||
| APC | OM2 | Multi Mode 50/125 | DX | Duplex | L | LSZH | A | Aqua | … | … | |||||
| FC | |||||||||||||||
| OM3 | Multi Mode 50/125 | V | Violet | 30 | 3.0mm | ||||||||||
| 99 | 99 m | ||||||||||||||
| MU | OM4 | Multi Mode 50/125 | |||||||||||||
