  • open -frame rack drawing

Rack Open Frame 36U

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

SKU: FCCC-1267 Categories: , ,

Rack Open Frame 36U is used to mount rackmount network equipment such as 19 inch patch panel, 19 inch fuse panel etc and also to manage cables in telecommunication salons, devices salon and data centers.

• Optimizing occupied space and holding heavy equipment.
• Easy cable management by embedding the clamp on rock body to hold cable
• Available in both height: 160cm, 180 cm and 220 cm
• Quick assembly of equipment by using special holes and rivets.
• Using stainless steel ST12 with 1.5 mm thickness to increase strength of structure
• Using electrostatic powder coating RAL 7035.
• Available accessories according to customer request
• Easy installation and & maintenance.

Specification  Parameter
 Rack unit 36 U
 Overal height (mm)  1550
 Width (mm) 600
 Depth (mm) 600
 Material  Steel ST12
 Standard  EIA/ECA-310-E
 Weight (kg)  18.2

Download Catalog
