• fiber patch cord types
  • MultiMode, Duplex, Indoor Fiber Optic Patch Cord
  • Single Mode, Duplex, Indoor Fiber Optic Patch Cord
  • 90 degree lc-lc duplex optic fiber patch cord
  • e2000 duplex fiber optic patch -cord
  • e2000-e2000 duplex fiber optic patch-cord cable

Duplex Fiber Optic Patch cord

Please do not hesitate to contact us if you require any further information

Features & Applications:

Duplex Fiber Optic Patch cord comprises of a fiber cable terminated with  two duplex connector at at either end  that allow rapidly  to connect to telecommunication equipment. The fiber optic patch cord come in many variations for fibers, cables and connectors.

It is suitable to use for telecom networks and also used for high speed metropolitan and
access network. Applications: Telecommunication Networks, Local Area Network (LAN), Connects Between fiber optic patch panel & network and etc.

  • Approved by Shahid Beheshti University, Communications Infrastructure, Telecommunication companies, Telecommunication Company of Iran, SAIRAN Electronics Ins, and Iran’s Ministry of Defense
  • SC, LC, ST,FC, MU connectors
  • Available in indoor or outdoor types
  • Jacket types PVC, LSZH & PE
  • Simplex or duplex, 0.9mm, 2.0mm or 3.0mm, OM1, OM2, OM3, OM4 multimode or OS1/OS2 (ITU-T G.652D), ITU-T G.657A1 & ITU-T G.657A2 single-mode
  • TIA-598-C standard colors
  • Return loss : PC>45 dB , UPC>55 dB , APC>60 dB , insertion loss<0.3dB (100% tested and recorded)
  • Premium quality Kevlar and aramid yarn
  • Small bend radius (7mm < R< 25mm)
  • Good exchangeability
  • Ceramic ferrules
  • Guaranteed quality and performance
  • Compatible with IEC, EIA(GR-326-Core)/TIA, ROHS, REACH,
Electrical and mechanical specification
Data Item
Optic Fiber Patch cord Product name
SM(OS1/OS2 (ITU-T G.652D), ITU-T G.657A1, ITU-T G.657A2)
MM (OM1, OM2, OM3, OM4)
Fiber type
SC/ST/FC/LC Connector type
0.9mm, 2mm, 3mm Product type
According to request of customer Length
PVC or LSZH or OFNR or OFNP(on request) Cable jacket type
Duplex Fiber Count
<0.2dB , max:0.3 dB Insertion Loss
PC>45 dB , UPC>55 dB , APC>60 dB Return loss
≤0.2 dB 1000 times mating cycles Repeatability
2 mm Cable Diameter
Yellow, Orange, Aqua Jacket Color
-40ºC to +85ºC Operating Temperature
ITU-T G.652D), ITU-T G.657A1, ITU-T G.657A2, IEC 60784-1, IEC 61300, GR-326-CORE, GR-1435, ISO/IEC 11801, AS/NZS ISO/IEC 14763.3, IEC 61280-4-1, UL 94, ANSI/TIA-598C & RoHS Standard



Item Connector Type Ferrule Type Fiber Type Cable Type Jacket Material Cable Color Cable Diameter Cable Length

Fiber Optic Patch- Cord

SC UPC G.652.D Single Mode 9/125 SX Simplex P PVC Y Yellow 9 0.9mm 01 01 m
G.657.A1 Single Mode 9/125
LC G.657.A2 Single Mode 9/125 O Orange
02 02 m
G.655 Single Mode 9/125 20 2.0mm
W Orange
ST OM1 Multi Mode 62.5/125
APC OM2 Multi Mode 50/125 DX Duplex L LSZH A Aqua
FC
OM3 Multi Mode 50/125 B Blue 30 3.0mm
99 99 m
MU OM4 Multi Mode 50/125 G Green
