8P AISG Female Connector

8P AISG Female Connector is manufactured according to the AISG Standard (AISG C 485) typically used for AISG outdoor applications. The Antenna Interface Standards Group (AISG) published this AISG standard to describe and define the AISG connector (based on IEC 60130-9).
AISG/RET connectors and cable assemblies for wireless infrastructure and RF telecom infrastructures with RET (Remote Electrical Tilt) components.

Main applications AISG Female connectors are industrial controls, data processing, instrumentation, medical devices, feed telecommunication network and equipment, plus outdoor and marine application.

Features & Applications:

  • Conform to IEC 61076-2-106 Standard
  • Torque screwdriver usable
  • For indoor and outdoor use
  • Very high quality
  • Mechanical operation: 500 mating cycles.
  • IP67 protection
  • Available in male or female types
  • The connector should be tightened by hand or by special torque scredriver
  • Compatible with industry cables from Andrew, Kathrein, Ericsson, Huawei, RFS, and many others
  • Compliant RoHS





Electrical and mechanical specification
Item Data
Product name 8P AISG Female
Connector Description 8 Pins Straight Female Connector for AISG RET Control Cable
Material and Plating
Center contact Phosphor Branze -Silver plated
Body Brass Plated Tri-metal
Insulator PTFE
Electrical Characteristics
Contact resistance 5 mΩ(Max)
Rated voltage 300V
Rated current 4 A (power supply)
(at 50 °C air temperature)
Working Temperature Range -40 °C~+80 °C
Mating cycles ≥500 times
Protection class IP 67
Standards IEC 61076-2-106



Download Catalog
