3/8″ Superflexible Jumper cable

3/8″ Superflexible Jumper cable

Please do not hesitate to contact us if you require any further information

Foreign Commercial Manager : +989125708854

FCCC Factory-Fit Jumper cable made from 3/8″ SCF and 7-16 DIN Female and 7-16 DIN Male Right Angle connectors. Connectors is soldered to cable in an industrial process under strict control to ensure the functioning of jumpers in high-performance wireless systems.  The Jumper is commonly used for for the connection of the RF cable lines with the antenna or with the radios in wireless systems.

• Designed for the harshest environmental condition
• High flexibility and small bending diameter
• High quality and excellent performances
• Low attenuation and VSWR
• Waterproof to safety class IP 68
• Flame retardant
• Available in variety of lengths and connectors
• 100% tested according to IEC and MIL Standards

Materials Specifications
Cable 3/8″  Super Flexible (SCF)
Jumper Type
Factory-Fit (Standard)
Length, m
2m, Based on customer requirements
Impedance
50 ± 1 Ω
Operating Frequency
DC-3GHz
Connector A Right Angle
Center Contact Connector A

Brass, silver plated

Outer Contact Connector A

Brass, nickel plated

Coupling Nut Connector A Hexagon nut, Nickel plated
Connector B 7-16 DIN Straight (Male/Female)
Center Contact Connector B Brass, silver plated
Outer Contact Connector B Brass, nickel plated
Coupling Nut Connector B Hexagon nut, Nickel plated
Dielectric
PTFE
Gasket Silicone rubber
Waterproof Rate
IP68
Jacket
Black Polyethylene,
VSWR (Return Loss, dB), typical
<1.15 @DC-3GHz
Intermodulation, 3rd Order, dBc
≤ -155dBc@2×20W
Operating Temperature, °C
-45 °C +85 °C
