مشخصات کلی General specifications |
|
Fiber Optic Connector, SC | Product name |
62.5/125μm OM1, 50/125μm OM2,10Gig 50/125μm laser optimized OM3/OM4 and 9/125μm OS1 |
Fiber compatibility |
<0.2db , max:0.3 dB | Insertion loss |
PC>45 dB , UPC>50dB , APC>60 dB | Return loss |
0.9mm, 2.0mm or 3.0mm | Cable size |
Zirconia Ceramic | Ferrule type |
< 0.2dB change, 500 mating cycles | Durability |
-40 to +85ºC | Temperature |
EIA/TIA-568A, JIS C 5973, ANSI, IEC RoHS |
Standard |
Ordering Information | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
