مشخصات کلی General specifications |
|
Optic Fiber Pigtail, Multi-mode, 0.9mm | Product name |
SC/ST/FC/LC | Connector type |
SM 2mm | Product type |
According to request of customer | Length |
PVC or LSZH or OFNR or OFNP(on request) | Cable jacket type |
Simplex | Fiber Count |
OS1/OS2 (ITU-T G.652D), ITU-T G.657A1, ITU-T G.657A2 | Fiber type |
<0.2dB | Insertion Loss |
PC>45 dB , UPC>55 dB , APC>60 dB | Return loss |
≤0.2 dB 1000 times mating cycles | Repeatability |
2 mm | Cable Diameter |
Yellow | Jacket Color |
-40ºC to +85ºC | Operating Temperature |
ITU-T G.652D), ITU-T G.657A1, ITU-T G.657A2, IEC 60784-1, IEC 61300, GR-326-CORE, GR-1435, ISO/IEC 11801, AS/NZS ISO/IEC 14763.3, IEC 61280-4-1, UL 94, ANSI/TIA-598C & RoHS |
Standard |
Ordering Information | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
