مشخصات کلی General specifications |
|
Data |
Item |
E2000 | Connector type |
SM or MM | Optical Fiber type |
Simplex or duplex | Fiber Count |
PVC or LSZH or OFNR(on request) |
Cable type |
0.9 mm | Tight-buffered Fiber Diameter |
0.9mm, 2mm, 3mm | Cable Diameter |
<0.2db , max:0.3 db |
Insertion Loss |
PC>45 db , UPC>55db , APC>60 db | Return loss |
< 50 μm |
Apex offset |
±100 nm | Fiber Height |
7mm < R< 25mm | Bend-face radius of curvature (operation ) |
<= 0.2 db 1000 times mating cycles | Repeatability |
-40 to +85c | Operating temperature |
