مشخصات کلی General specifications |
|
Fiber Optic Adaptor LC/LC | Product name |
Single-mode or Multi-mode | Mode |
Zirconia Ceramic | Sleeve |
For 0.9mm, 2.0mm or 3.0mm | Cable type |
Simplex or Duplex or Quad | Channels |
0.2dB | Insertion loss Max |
±0.01dB | Repeatability |
<0.15dB change, 1000 mating cycles | Durability |
80N | Strength of coupling mechanism |
Metal wings | Mounting |
-40C +85C | Operating Temperature |
-40C +85C | Storage Temperature |
Mounting
